Merkel U-Ring TM 21

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
24359833 1160 1110 31.9 35
24368191 950 900 30.9 34
24372489 800 750 30.5 33.5
24377403 710 670 23.7 26
24368188 680 640 29.1 32
24368186 600 560 23.7 26
24370483 560 530 23.7 26
24368184 500 470 23.7 26
24368183 480 450 23.7 26
24368182 470 440 23.7 26
24371311 460 420 29.1 32
24368180 450 420 23.7 26
24368179 430 400 23.7 26
24368178 420 390 23.7 26
24362505 400 370 23.7 26
24368177 400 360 29.1 32
24363187 380 350 23.7 26
24370481 360 330 23.7 26
24368208 360 320 29.1 32
24370480 350 320 20.9 23
529099 340 310 20.9 23
24368175 330 300 20.9 23
24373867 320 280 29.1 32
24368174 310 280 20.9 23
24368173 300 270 20.9 23
24367971 280 250 20.9 23
24368171 250 220 20.9 23
24368170 240 210 20.9 23
24368169 230 200 20.9 23
24368168 220 190 20.9 23
24370479 210 180 20.9 23
24370478 180 150 17.2 19
24370477 160 130 17.2 19
