Installation dimensions
  • Inside Diameter ID
    mm
  • Outside Diameter OD
    mm
  • Groove section H1
    mm
  • Groove Width H2
    mm

Merkel U-Ring NA 400

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
4618 320 285 20 21
4624 320 280 23 24
4610 280 250 18 19
25496 250 220 18 19
25503 250 215 20 21
4580 220 195 15 16
25495 220 190 18 19
25491 200 175 15 16
25493 200 170 18 19
3631 180 150 18 19
25464 160 135 15 16
25474 160 130 18 19
30033 150 125 15 16
30030 140 120 12 13
25440 125 105 12 13
25452 125 100 15 16
30026 120 100 12 13
35943 115 90 15 16
30021 110 90 12 13
25415 100 80 12 13
25427 100 75 15 16
30011 90 70 12 13
25354 80 65 10 11
25383 80 60 12 13
25404 80 55 15 16
30009 75 55 12 13
4566 70 50 12 13
25330 63 48 10 11
25351 63 43 12 13
30008 60 40 12 13
4565 55 40 10 11
25306 50 35 10 11
25325 50 30 12 13
4561 45 30 10 11
25289 40 25 10 11
25287 32 17 10 11
25279 25 15 8 9
