Merkel U-Ring NA 250
Product search
Cart 0
Products
Quantity
Quotes request
Product categories
Brands
Part No.
Installation dimensions
  • Inside Diameter ID
    mm
  • Outside Diameter OD
    mm
  • Groove section H1
    mm
  • Groove Width H2
    mm

Merkel U-Ring NA 250

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
29462 180 160 15 16
21094 160 135 18 19
2920 140 125 15 16
17613 140 115 15 16
18504 130 110 15 16
18498 125 105 15 16
18501 125 100 15 16
18494 120 100 15 16
18496 120 95 15 16
18491 115 90 15 16
18485 110 95 12 13
18486 110 90 15 16
17614 110 85 15 16
18481 105 90 12 13
18484 105 85 15 16
18480 100 85 12 13
18479 100 80 15 16
18478 95 75 12 13
18475 90 75 12 13
18476 90 70 12 13
18469 85 70 12 13
18467 82 65 12 13
18465 80 65 12 13
18466 80 60 12 13
18460 75 60 12 13
18456 70 55 12 13
18457 70 50 12 13
18452 65 50 10 11
18453 65 45 12 13
18451 63 45 12 13
18449 60 45 10 11
18450 60 40 12 13
18446 55 40 10 11
18442 50 35 10 11
18443 50 30 12 13
18436 45 30 10 11
18434 42 30 10 11
32166 42 22 10 11
18432 40 25 10 11
18429 38 25 10 11
18426 35 22 10 11
4429 32 20 10 11
