Installation dimensions
  • Inside Diameter ID
    mm
  • Outside Diameter OD
    mm
  • Groove section H1
    mm
  • Groove Width H2
    mm

B1

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
430099 500 540 20
31704 500 540 20
31702 480 520 20
477548 460 500 20
31700 460 500 20
429204 440 480 20
2536 440 480 20
31668 420 460 20
31653 400 440 20
31667 380 420 20
2533 360 400 20
20447 350 380 16
31645 340 380 20
17866 320 360 20
13450 300 340 20
2526 280 320 20
359071 270 310 16
12086 250 280 15
27251 240 270 15
20859 230 260 15
20441 230 255 10
20444 220 250 15
20440 220 250 11
19997 205 230 15
26728 200 230 15
19992 180 215 16
19988 160 190 15
19987 160 190 13
19985 155 190 15
31533 145 175 15
19979 135 170 15
19565 128 150 15
19974 125 160 13
14766 125 160 12
2610 120 160 12
2776 115 140 12
13859 115 135 13
19562 112 130 12
13810 110 128 9
19967 105 145 15
19966 105 140 13
439794 105 135 13
19635 95 125 12
19557 95 110 9
19951 90 130 13
432607 85 120 12
2755 85 120 12
19942 85 110 13
19932 80 110 10
31819 78 100 10
19927 76 95 10
19924 75 105 13
19915 72 100 10
23821 72 84 7
19909 70 95 13
26008 68 78 7
21022 67 80 10
121796 64 80 8
18195 63 85 10
31506 62 90 10
19889 62 85 10
21017 62 75 10
19542 61 75 8
19878 60 78 10
18349 60 70 7
28930 56 70 8
2659 55 85 8
18428 53.98 73.03 6.4
19857 52 72 10
2655 52 72 8
19855 50.8 76.2 9.5
19853 50 90 10
19851 50 80 13
19849 50 75 9
19844 50 68 14
19521 50 66 10
20265 48 72 12
14027 48 72 8
12011331 48 65 10
19836 47 72 12
19831 45 80 13
19504 45 62 7
19815 44 65 10
19494 42 58 9
7994 42 56 7
19801 40 72 12
2567 40 72 7
19797 40 68 12
19792 40 60 12
19483 40 55 8
21706 40 52 12
7990 39 52 6.5
19785 38 56 12
19782 38 54 10
20316 36 58 10
19471 36 52 9
31481 36 50 7
20250 36 47 7
19769 35 60 10
19765 35 55 12
19447 34 52 7
19445 34 47 9
20275 34 45 7
19443 32 50 7
19750 32 47 10
19436 32 42 7
19745 30 55 12
19738 30 48 10
7979 30 47 8
20417 30 42 6
19733 28 47 10
2730 28 47 7
19415 28 42.9 9.5
19732 28 42.5 8
19413 28 42 8
251 28 42 7
19410 28 40 7
19731 27 47 10
19728 26 42.9 9.5
19407 26 37 7
19720 25 42.9 9.5
19719 25 42 10
19395 25 40 6
19394 25 38 7
2723 24 47 7
7942 24 37 7
19388 24 36 6
13985 24 35 7
2720 22 47 7
19708 22 42 10
13976 22 40 7
20259 22 35 8
19371 21 32 7
19369 21 30 6.5
19699 20 40 10
19363 20 40 7
19362 20 40 7
19360 20 37 6
383388 20 28 6
19346 19 32 7
19345 18 32 7
11350 18 24 4
7893 17 34 4
19330 17 28 6
2748 16 35 7
19686 16 30 10
19328 16 30 7
19325 16 26 7
22979 16 24 7
20397 16 24 6
8017 15 37 10
7878 15 26 7
2680 14 30 7
19311 14 26 7
21702 14 25 7
7831 14 24 7
19306 13 22 5
23833 13 20 4
19304 12 32 7
19303 12 32 5
2673 12 30 7
7819 12 28 7
7809 12 24 7
19299 12 22 7
20296 12 20 5
32193 11 17 4
19290 10 24 7
19279 9 17 4.5
19277 8 28 7
19276 8 24 7
7797 7 16 7
18256 6 16 7
