Part No.
Installation dimensions
  • Inside Diameter ID
    mm
  • Outside Diameter OD
    mm
  • Groove section H1
    mm
  • Groove Width H2
    mm

TTH

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
TTH 934 220 240 16
TTH 933 200 225 20
TTH 932 180 205 20
TTH 931/1 160 185 20
TTH 931/2 160 180 16
TTH 931 160 180.5 7.5
TTH 930/1 150 170 16
TTH 930 145 165.6 7.9
TTH 929/1 142 157 10
TTH 929/2 140 160 17
TTH 929 140 160 16
TTH 928 130 150.6 7.9
TTH 927 125 145 16
TTH 926 125 140.5 6.3
TTH 925 120 135 16
TTH 924 117 132 10
TTH 923 115 130 13
TTH 922 110 130 16
TTH 921 106 121.5 6.3
TTH 920 100 120 16
TTH 919/1 95 110 13
TTH 919 95 110 13
TTH 918/1 90 105 12.5
TTH 918 90 105 13
TTH 917 90 105 6.3
TTH 916 85 100.5 6.3
TTH 915/1 85 100 12.5
TTH 915 85 100 13
TTH 914 82.55 98.2 13
TTH 913 80 95 6.3
TTH 912 80 95 12.5
TTH 911/1 75 90 12.5
TTH 911 75 90 13
TTH 910 75 90.5 6.3
TTH 909/1 70 90 13
TTH 909 70 85 12.5
TTH 908 65 80 13
TTH 907 63 78 12.5
TTH 906 63 78 6.3
TTH 905/1 60 80 13
TTH 905 60 75 13
TTH 904 56 71 12.5
TTH 903/1 56 66 10
TTH 903/2 50 65 11
TTH 903 50 65 12.5
TTH 902 45 55 8
TTH 901 40 50 8
TTH 900 32 42 8
