Installation dimensions
  • Inside Diameter ID
    mm
  • Outside Diameter OD
    mm
  • Groove section H1
    mm
  • Groove Width H2
    mm

GHP

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Download Technical Details (PDF)
Part No. ID OD H1 H2 Quantity Pick
GHP 210 210 222 5.5 10
GHP 180 180 192 5.5 10
GHP 175 175 187 5.5 10
GHP 150 150 162 5.5 10
GHP 145 145 157 5.5 10
GHP 140 140 152 5.5 10
GHP 135 135 147 5.5 10
GHP 130 130 142 5.5 10
GHP 125 125 137 5.5 10
GHP 120 120 132 5.5 10
GHP 117 117 129 5.5 10
GHP 115 115 127 5.5 10
GHP 110 110 122 5.5 10
GHP 106 106 118 5.5 10
GHP 100 100 108 4 7
GHP 95 95 103 4 7
GHP 90 90 98 4 7
GHP 85 85 93 4 7
GHP 80 80 88 4 7
GHP 75 75 83 4 7
GHP 70 70 78 4 7
GHP 65 65 73 4 7
GHP 63 63 71 4 7
GHP 60 60 68 4 7
GHP 56 56 64 4 7
GHP 55 55 63 4 7
GHP 50 50 58 4 7
GHP 45 45 53 4 7
GHP 42 42 50 4 7
GHP 40 40 48 4 7
GHP 36 36 44 4 7
GHP 35 35 43 4 7
GHP 32 32 40 4 7
GHP 30 30 38 4 7
GHP 28 28 36 4 7
GHP 25 25 33 4 7
GHP 22 22 30 4 7
GHP 20 20 28 4 7
GHP 18 18 26 4 7
GHP 16 16 24 4 7
GHP 16/1 16 22 3 5
GHP 12 12 20 4 7
